名稱 |
appellation |
ZDQQ-600 | ZDQQ-800 |
| 工作臺尺寸 |
worktable dimensions |
3200x2000mm |
3200x2000mm |
| 設備外形尺寸 |
dimension of external form |
6000x5000x2800mm |
6000x5000x2900mm |
| 鋸片直徑 |
saw blade diameter |
350-600mm |
350-600mm |
| 主電機功率 |
main motor power |
1.5kw |
18.5kw |
| 前后電機功率 |
after motor power |
1.5kw |
1.5kw |
| 左右電機功率 |
about motor power |
1.5kw |
1.5kw |
|
翻轉，升降，轉臺油泵電機功率 |
Power of oil pump motor on rotary lifting turntable |
2.2kw |
2.2kw |
| 臺面轉角 |
range of trolley |
0-90n° |
0-90n° |
| 切割行程（前后） |
cutting range front/rear |
3200mm |
3200mm |
| 切割行程（左右） |
cutting range left/right |
3500mm |
3500mm |
| 切割行程（上下） |
cutting range up/down |
450mm |
520mm |
|
總重量 |
weigh |
≈6500kg |
≈6800kg |
注：加工長寬尺寸和設備外型尺寸，電機功率，可根據客戶需要制作對應尺寸。
Remark: the processing dimensions (length and width), overall dimension of equipment and motor power are subject to customers’demands.
